Heat Treatment Unit at Taloja
| Specification | Description |
| No. of Furnaces | 5 |
| Furnace type | Front opening box (Batch type) |
| Max. Operating temperature | 1200ºC |
| Max. Charge dimensions (mm) | 2400 L * 1500 B * 1000 H for 4 Furnace 3000 L * 2300 B * 1000 H for 1 Furnace |
| Max. Charge weight | 2500 kgs |
| Max. Quench delay | 90 seconds |
| Temperature Control Accuracy | ± 8ºC |
| Furnace Insulation | Ceramic fiber blanket |
| Quenching tanks & Capacity | 2 (Oil & water) – 20 KL each |
Other Details :
- PNG (Natural Gas) fired Furnaces.
- All Temperature Instruments, PID Controllers, Thermocouples & Furnaces are Calibrated by NABL approved agencies, as per
- API 6A (Annexture-M)
- AMS 2750 latest edition,
- Strip chart type Time-temperature graph recorder installed.
- Two thermocouples installed in each furnace.
- 62.5 KVA Diesel generator for back-up.
- Rotatory manipulator for the movement of material
- Brinell Hardness Machines for Quality control, by NABL approved agency.
